Technical Specifications
| Specification | Details |
|---|---|
| Nominal Voltage | 24V |
| Capacity | 5.12kWh (200Ah) |
| Cycle Life | 6000+ cycles @ 25°C |
| Charge Voltage | 28.8V |
| Discharge Voltage Range | 24V – 28.8V |
| Max Charge/Discharge Current | 100A @ 30s |
| Rated Charge/Discharge Current | 50A |
| Ingress Protection | IP21 |
| Working Temperature | -10°C to 50°C |
| Dimensions (L x W x H) | 440mm x 585mm x 145mm |
| Weight | 41 Kg |
