Specifications:
- Rated Power: 5000VA / 5000W, providing ample power for a range of applications.
- Parallel Capability: Can be expanded with up to 6 units for larger energy requirements.
- AC Voltage Regulation (Battery Mode): Stable output with 230VAC ± 5% at 50/60Hz.
- Surge Power: A strong 10000VA for handling high initial loads.
- Maximum Efficiency: Up to 93%, ensuring most energy captured is converted to usable power.
- Waveform: Outputs a clean and stable pure sine wave.
- Transfer Time: 10ms typical, 20ms Max for smooth transition between power sources.
- Maximum PV Array Power: Supports a solar array up to 6000W for extensive energy harvesting.
- MPPT Range @ Operating Voltage: Wide range from 120VDC to 430VDC for optimal solar panel performance.
- Number of Independent MPP Trackers/Strings Per MPP Tracker: 1/1, for efficient solar tracking.
- Maximum PV Array Open Circuit Voltage: Tolerates up to 450VDC, allowing flexibility in solar array design.
- Maximum Solar Charge Current: High capacity 100A for quick and efficient battery charging.
- AC Input Voltage: Designed to work with a standard 230 VAC input.
- Frequency Range: Auto sensing 50Hz/60Hz to align with grid or generator frequencies.
- Protection: Rated at IP20, providing protection against objects larger than 12.5mm.
