Technical Specifications
| Specification | Details |
|---|---|
| Brand | SRNE (High-Frequency Series) |
| Model | 12kW 3-Phase High-Frequency Hybrid Inverter |
| Rated Power | 12,000W (12kW) |
| Voltage Output | 220V–240V per phase |
| System Voltage | 48V DC |
| Max PV Input Voltage | 500VDC |
| Solar Input Capacity | Up to 8000W |
| Max Charging Current | 120A |
| Efficiency | >95% |
| Waveform | Pure Sine Wave |
| Surge Capacity | 200–250% of rated power |
| Weight | Approx. 28–35kg |
| Monitoring | Built-in LCD (Wi-Fi optional) |
