Key Features:
- Long Life Guaranteed: Experience over 6,000 cycles at 80% Depth of Discharge (DoD), ensuring a lifespan exceeding 10 years.
- Built-in Battery Management System (BMS): The intelligent BMS provides comprehensive protection against overcharging, over-discharging, overcurrent, short circuits, and temperature variations, ensuring optimal performance and safety.
- Expandable Capability: Easily scale your energy storage by connecting up to six units in parallel, accommodating your growing energy needs.
- High Energy Density: Utilizing advanced LiFePO₄ technology, this battery delivers higher energy density, resulting in a more compact and space-saving design ideal for household use.
- Wide Compatibility: Compatible with leading inverter brands, including Growatt and Deye, facilitating seamless integration into your existing solar setup.
- Eco-Friendly: LiFePO₄ batteries are known for their environmental friendliness, containing no toxic heavy metals and offering a sustainable energy storage solution.
Specifications:
- Model: LPBF48200-H
- Usable Capacity: 10.0 kWh
- Nominal Voltage: 51.2V
- Voltage Range: 48V – 57.6V
- Maximum Charge & Discharge Current: 120A
- Recommended Charge & Discharge Current: ≤80A
- Maximum Output Power: 6,000W
- Depth of Discharge (DoD): ≥95%
- Cycle Life: ≥6,000 cycles at 25°C, 80% DoD
- Ingress Protection: IP21
- Working Temperature Range:
- Discharge: -20°C to +65°C
- Charge: 0°C to +55°C
- Net Weight: Approximately 75 kg
- Dimensions: 685 mm x 475 mm x 213 mm
